Memory Map

Non-Confidential

Unrestricted Access

Table 4-2 shows the permissions of the processor memory regions.

Note

Private Peripheral Bus and System space at

0xE0000000 - 0xFFFFFFFF

are permanently

XN. The MPU cannot change this.

For a description of the processor bus interfaces, see Chapter 12 Bus Interface.

Table 4-2 Memory region permissions

Name Region Device type XN Cache

Code

0x00000000-0x1FFFFFFF

Normal - WT

SRAM

0x20000000-0x3FFFFFFF

Normal - WBWA

SRAM_1M +0000000 - - -

SRAM_31M +0100000 - -

SRAM_bitband +2000000 Internal - -

SRAM +4000000 - - -

Peripheral

0x40000000-0x5FFFFFFF

Device XN -

Periph_1IM +0000000 - - -

Periph_31IM +0100000 - - -

Periph_bit band +2000000 Internal - -

Peripheral +4000000 - - -

External RAM

0x60000000-0x7FFFFFFF

Normal - WBWA

External RAM

0x80000000-0x9FFFFFFF

Normal - WT

External Device

0xA0000000-0xBFFFFFFF

Device XN -

External Device

0xC0000000-0xDFFFFFFF

Device XN -

System

0xE0000000-0xFFFFFFFF

-XN-

Private Peripheral Bus +0000000 SO, shared XN -

Vendor_SYS +0100000 Device XN -
