ARM Cortex-M3 User Manual

Memory Protection Unit
ARM DDI 0337G Copyright © 2005-2008 ARM Limited. All rights reserved. 9-9
Unrestricted Access Non-Confidential
Figure 9-5 MPU Region Attribute and Size Register bit assignments
Table 9-6 describes the bit assignments of the MPU Region Attribute and Size Register.
For more information, see MPU access permissions on page 9-13.
31 29 28 27 26 24 23 22 21 19 18 17 16 15 8 7 6 5 1 0
Res
SRD SIZE
X
N
e
s
R
AP Res. TEX S C B Res.
E
N
A
Table 9-6 MPU Region Attribute and Size Register bit assignments
Bits Field Function
[31:29] - Reserved.
[28] XN Instruction access disable bit:
1 = disable instruction fetches
0 = enable instruction fetches.
[27] - Reserved.
[26:24] AP Data access permission field:
Value Privileged permissions User
permissions
b000
b001
b010
b011
b100
b101
b110
b111
No access
Read/write
Read/write
Read/write
Reserved
Read-only
Read-only
Read-only
No access
No access
Read-only
Read/write
Reserved
No access
Read-only
Read-only.
[23:22] - Reserved.
[21:19] TEX Type extension field.
[18] S Shareable bit:
1 = shareable
0 = not shareable.
[17] C Cacheable bit:
1 = cacheable
0 = not cacheable.
