ARM Cortex-M3 User Manual

Trace Port Interface Unit
ARM DDI 0337G Copyright © 2005-2008 ARM Limited. All rights reserved. 17-17
Table 17-12 lists the bit assignments of the Integration Mode Control Register
Integration Register: TRIGGER
The register address, access type, and Reset state are:
Address
0xE0040EE8
Access Read only
Reset state
0x0
Figure 17-11 shows the bit assignments of the Integration Register : TRIGGER.
Figure 17-11 Integration Register : TRIGGER bit assignments
Table 17-13 lists the bit assignments of the Integration Register : TRIGGER bit
assignments.
Integration Register : FIFO data 0
The register address, access type, and Reset state are:
Address
0xE0040EEC
Access Read only
Table 17-12 Integration Mode Control Register bit assignments
Bits Field Function
[31:2] - Reserved, SBZ
[1] FIFO test mode Enables FIFO test mode
[0] Integration test mode Enables integration test mode
Reserved
31 0
1
TRIGGER input value
Table 17-13 Integration Register : TRIGGER bit assignments
Bits Field Function
[31:1] - Reserved
[0] TRIGGER input value Enables the TRIGGER input
