Signal Descriptions
ARM DDI 0337G Copyright © 2005-2008 ARM Limited. All rights reserved. A-11
Unrestricted Access Non-Confidential
A.9 Private Peripheral Bus interface
Table A-9 lists the signals of the PPB interface.
Table A-9 Private Peripheral Bus interface
Name Direction Description
PADDR[19:2] Output 17-bit address. Only the bits that are relevant to the External Private Peripheral Bus are
driven.
PADDR31 Output This signal is driven HIGH when the AHB-AP is the requesting master. It is driven
LOW when DCore is the requesting master.
PSEL Output Indicates that a data transfer is requested.
PENABLE Output Strobe to time all accesses. Indicates the second cycle of an APB transfer.
PWDATA[31:0] Output 32-bit write data bus.
PWRITE Output Write not read.
PRDATA[31:0] Input Read data bus.
PREADY Input APB slave ready.
PSLVERR Input APB slave error.
