Page #385 background image
Signal Descriptions
ARM DDI 0337G Copyright © 2005-2008 ARM Limited. All rights reserved. A-13
Unrestricted Access Non-Confidential
A.11 AHB-AP interface
Table A-11 lists the signals of the AHB-AP interface.
Table A-11 AHB-AP interface
Name Direction Description
DAPRDATA[31:0] Output The read bus is driven by the selected AHB-AP during read cycles when
DAPWRITE is LOW.
DAPREADY Output The AHB-AP uses this signal to extend a DAP transfer.
DAPSLVERR Output The error response is because of:
Master port produced an error response, or transfer not initiated because of
DAPEN preventing a transfer.
Access to AP register not accepted after a DAPABORT operation.
DAPCLKEN Input DAP clock enable (power saving).
DAPEN Input AHB-AP enable.
DAPADDR[31:0] Input DAP address bus.
DAPSEL Input Select signal generated from the DAP decoder to each AP. This signal indicates that
the slave device is selected, and a data transfer is required. There is a DAPSEL
signal for each slave. The signal is not generated by the driving DP. The decoder
monitors the address bus and asserts the relevant DAPSEL.
DAPENABLE Input This signal indicates the second and subsequent cycles of a DAP transfer from DP
to AHB-AP.
DAPWRITE Input When HIGH indicates a DAP write access from DP to AHB-AP. When LOW
indicates a read access.
DAPWDATA[31:0] Input The write bus is driven by the DP block during write cycles when DAPWRITE is
HIGH.
DAPABORT Input Aborts the current transfer. The AHB-AP returns DAPREADY HIGH without
affecting the state of the transfer in progress in the AHB Master Port.
FIXMASTERTYPE Input Setting this signal to 1 overrides the MasterType bit of the AHB-AP Control and
Status Word (CSW). This ensures accesses from the debugger is always issued as
0x1
on HMASTERD and HMASTERS regardless of the MasterType setting in the
CSW.
