ARM Cortex-M3 User Manual

Programmer’s Model
2-16 Copyright © 2005-2008 ARM Limited. All rights reserved. ARM DDI 0337G
Non-Confidential
Unrestricted Access
Table 2-5 lists the 32-bit Cortex-M3 instructions.
Store register halfword [15:0] to register address + register offset STRH <Rd>, [<Rn>, <Rm>]
Subtract immediate 3-bit value from register SUB <Rd>, <Rn>, #<immed_3>
Subtract immediate 8-bit value from register value SUB <Rd>, #<immed_8>
Subtract register values SUB <Rd>, <Rn>, <Rm>
Subtract 4 (immediate 7-bit value) from SP SUB SP, #<immed_7> * 4
Operating system service call with 8-bit immediate call code SVC <immed_8>
Extract byte [7:0] from register, move to register, and sign-extend to 32 bits SXTB <Rd>, <Rm>
Extract halfword [15:0] from register, move to register, and sign-extend to 32 bits SXTH <Rd>, <Rm>
Test register value for set bits by ANDing it with another register value TST <Rn>, <Rm>
Extract byte [7:0] from register, move to register, and zero-extend to 32 bits UXTB <Rd>, <Rm>
Extract halfword [15:0] from register, move to register, and zero-extend to 32 bits UXTH <Rd>, <Rm>
Wait for event WFE <c>
Wait for interrupt WFI <c>
Table 2-4 16-bit Cortex-M3 instruction summary (continued)
Operation Assembler
Table 2-5 32-bit Cortex-M3 instruction summary
Operation Assembler
Add register value, immediate 12-bit value, and C bit
ADC{S}.W <Rd>, <Rn>, #<modify_constant(immed_12>
Add register value, shifted register value, and C bit ADC{S}.W <Rd>, <Rn>, <Rm>{, <shift>}
Add register value and immediate 12-bit value ADD{S}.W <Rd>, <Rn>, #<modify_constant(immed_12)>
Add register value and shifted register value ADD{S}.W <Rd>, <Rm>{, <shift>}
Add register value and immediate 12-bit value ADDW.W <Rd>, <Rn>, #<immed_12>
Bitwise AND register value with immediate 12-bit value AND{S}.W <Rd>, <Rn>, #<modify_constant(immed_12>
Bitwise AND register value with shifted register value AND{S}.W <Rd>, <Rn>, Rm>{, <shift>}
Arithmetic shift right by number in register ASR{S}.W <Rd>, <Rn>, <Rm>

ARM Cortex-M3 Specifications

General

Architecture	ARMv7-M
Instruction Set	Thumb-2
Pipeline Stages	3-stage
Interrupts	Nested Vectored Interrupt Controller (NVIC)
Interrupt Controller	Nested Vectored Interrupt Controller (NVIC)
Memory Protection Unit	Optional
Power Consumption	Varies by implementation
Max Clock Speed	Up to 100 MHz
Debugging	JTAG and Serial Wire Debug (SWD)
Operating Voltage	1.8V to 3.6V
Manufacturing Process	Varies by implementation
Core Type	32-bit
