ARM Cortex-M3 User Manual

Programmer’s Model
ARM DDI 0337G Copyright © 2005-2008 ARM Limited. All rights reserved. 2-17
Unrestricted Access Non-Confidential
Conditional branch B{cond}.W <label>
Clear bit field BFC.W <Rd>, #<lsb>, #<width>
Insert bit field from one register value into another BFI.W <Rd>, <Rn>, #<lsb>, #<width>
Bitwise AND register value with complement of immediate
12-bit value
BIC{S}.W <Rd>, <Rn>, #<modify_constant(immed_12)>
Bitwise AND register value with complement of shifted
register value
BIC{S}.W <Rd>, <Rn>, <Rm>{, <shift>}
Branch with link BL <label>
Branch with link (immediate) BL<c> <label>
Unconditional branch B.W <label>
Clear exclusive clears the local record of the executing
processor that an address has had a request for an exclusive
access.
CLREX <c>
Return number of leading zeros in register value CLZ.W <Rd>, <Rn>
Compare register value with two’s complement of immediate
12-bit value
CMN.W <Rn>, #<modify_constant(immed_12)>
Compare register value with two’s complement of shifted
register value
CMN.W <Rn>, <Rm>{, <shift>}
Compare register value with immediate 12-bit value CMP.W <Rn>, #<modify_constant(immed_12)>
Compare register value with shifted register value CMP.W <Rn>, <Rm>{, <shift>}
Data memory barrier DMB <c>
Data synchronization barrier DSB <c>
Exclusive OR register value with immediate 12-bit value EOR{S}.W <Rd>, <Rn>, #<modify_constant(immed_12)>
Exclusive OR register value with shifted register value EOR{S}.W <Rd>, <Rn>, <Rm>{, <shift>}
Instruction synchronization barrier ISB <c>
Load multiple memory registers, increment after or decrement
before
LDM{IA|DB}.W <Rn>{!}, <registers>
Table 2-5 32-bit Cortex-M3 instruction summary (continued)
Operation Assembler

ARM Cortex-M3 Specifications

General

Architecture	ARMv7-M
Instruction Set	Thumb-2
Pipeline Stages	3-stage
Interrupts	Nested Vectored Interrupt Controller (NVIC)
Interrupt Controller	Nested Vectored Interrupt Controller (NVIC)
Memory Protection Unit	Optional
Power Consumption	Varies by implementation
Max Clock Speed	Up to 100 MHz
Debugging	JTAG and Serial Wire Debug (SWD)
Operating Voltage	1.8V to 3.6V
Manufacturing Process	Varies by implementation
Core Type	32-bit
