Appendix B

Revisions

This appendix describes the technical changes between released issues of this book.

Table B-1 lists the differences between issue E and issue F, and Table B-2 on page B-5

lists the differences between issue F and issue G.

Table B-1 Differences between issue E and issue F

Change Location

Introductory processor information updated About the processor on page 1-2

Processor block diagram updated Figure 1-1 on page 1-5

Introductory information added, including:

• TPIU subsection

• Addition of note to SW/SWJ-DP subsection

• ROM table subsection.

Introductory processor core information updated Processor core on page 1-5

APB bus now version 3.0 Bus matrix on page 1-7
