Page #59 background image
Programmer’s Model
ARM DDI 0337G Copyright © 2005-2008 ARM Limited. All rights reserved. 2-11
Unrestricted Access Non-Confidential
2.5 Memory formats
The processor views memory as a linear collection of bytes numbered in ascending
order from 0. For example:
bytes 0-3 hold the first stored word
bytes 4-7 hold the second stored word.
The processor can access data words in memory in little-endian format or big-endian
format. It always accesses code in little-endian format.
Note
Little-endian is the default memory format for ARM processors.
In little-endian format, the byte with the lowest address in a word is the least-significant
byte of the word. The byte with the highest address in a word is the most significant.
The byte at address 0 of the memory system connects to data lines 7-0.
In big-endian format, the byte with the lowest address in a word is the most significant
byte of the word. The byte with the highest address in a word is the least significant. The
byte at address 0 of the memory system connects to data lines 31-24.
Figure 2-5 on page 2-12 shows the difference between little-endian and big-endian
memory formats.
The processor contains a configuration pin, BIGEND, that enables you to select either
the little-endian or BE-8 big-endian format. This configuration pin is sampled on reset.
You cannot change endianness when out of reset.
Note
Accesses to System Control Space (SCS) are always little endian.
Attempts to change endianness while not in reset are ignored.
Private Peripheral Bus (PPB) space is little-endian, irrespective of the setting of
BIGEND.
