Debug Port
13-2 Copyright © 2005-2008 ARM Limited. All rights reserved. ARM DDI 0337G
Non-Confidential
Unrestricted Access
13.1 About the DP
The processor contains an Advanced High-performance Bus Access Port (AHB-AP)
interface for debug accesses. An external DP component accesses this interface. The
Cortex-M3 system supports three possible DP implementations:
•The Serial Wire JTAG Debug Port (SWJ-DP). The SWJ-DP is a standard
CoreSight debug port that combines JTAG-DP and Serial Wire Debug Port
(SW-DP).
The SW-DP. This provides a two-pin (clock + data) interface to the AHB-AP port.
No DP present. If no debug functionality is present within the processor, a DP is
not required.
Note
The SWJ-DP is designed to permit pin sharing of JTAG-TDO and JTAG-TDI when
they are not being used for JTAG debug access. When used together with a Cortex-M3
TPIU, there are different options for the connection of Serial Wire Output (SWO), see
Serial wire output connection on page 17-21.
The two DP implementations provide different mechanisms for debug access to the
processor. Your implementation must contain only one of these components.
Note
Your implementation might contain an alternative implementor-specific DP instead of
SW-DP or SWJ-DP. See your implementor for details.
For more detailed information on the DP components, see the CoreSight Components
Technical Reference manual.
For more information on the AHB-AP, see AHB-AP on page 11-39.
The DP and AP together are referred to as the Debug Access Port (DAP).
For more detailed information on the debug interface, see the ARM Debug Interface v5,
Architecture Specification.
