ARM Cortex-M3 User Manual

AC Characteristics
19-6 Copyright © 2005-2008 ARM Limited. All rights reserved. ARM DDI 0337G
Non-Confidential
Unrestricted Access
Table 19-10 shows the timing parameters for the low power output ports.
Table 19-11 shows the timing parameters for the AHB output ports.
Clock uncertainty 50% CURRPRI[7:0]
Clock uncertainty 70% TRCENA
Clock uncertainty 50% INTERNALSTATE
Table 19-10 Low power output ports timing parameters
Output delay Min. Output delay Max. Signal name
Clock uncertainty 50% SLEEPING
Clock uncertainty 50% SLEEPDEEP
Clock uncertainty 50% SLEEPHOLDACKn
Clock uncertainty 50% WICLOAD
Clock uncertainty 50% WICCLEAR
Clock uncertainty 50% WICDSACKn
Clock uncertainty 50% WICMASKNMI
Clock uncertainty 50% WICMASKMON
Clock uncertainty 50% WICMASKISR
Clock uncertainty 50% WICMASKRXEV
Table 19-11 AHB output ports timing parameters
Output delay Min. Output delay Max. Signal name
Clock uncertainty 50% HTRANSI[1:0]
Clock uncertainty 50% HSIZEI[2:0]
Clock uncertainty 50% HPROTI[3:0]
Clock uncertainty 50% MEMATTRI[1:0]
Table 19-9 Miscellaneous output ports timing parameters (continued)
Output delay Min. Output delay Max. Signal name

ARM Cortex-M3 Specifications

General

Architecture	ARMv7-M
Instruction Set	Thumb-2
Pipeline Stages	3-stage
Interrupts	Nested Vectored Interrupt Controller (NVIC)
Interrupt Controller	Nested Vectored Interrupt Controller (NVIC)
Memory Protection Unit	Optional
Power Consumption	Varies by implementation
Max Clock Speed	Up to 100 MHz
Debugging	JTAG and Serial Wire Debug (SWD)
Operating Voltage	1.8V to 3.6V
Manufacturing Process	Varies by implementation
Core Type	32-bit
