11.3 System debug programmer’s model

This section lists and describes the debug registers for all the system debug components.

It contains:

• FPB on page 11-6

• DWT on page 11-13

• ITM on page 11-30

• AHB-AP on page 11-39.

Note

• For a description of the Core debug registers, see Core debug registers on

page 10-3.

• For a description of the SWJ-DP and SW-DP registers see Chapter 13 Debug

Port.

• For a description of the TPIU, see Chapter 17 Trace Port Interface Unit.
