ARM Cortex-M3 User Manual

Nested Vectored Interrupt Controller
ARM DDI 0337G Copyright © 2005-2008 ARM Limited. All rights reserved. 8-19
Unrestricted Access Non-Confidential
Interrupt Control State Register
Use the Interrupt Control State Register to:
• set a pending Non-Maskable Interrupt (NMI)
• set or clear a pending SVC
• set or clear a pending SysTick
• check for pending exceptions
• check the vector number of the highest priority pended exception
• check the vector number of the active exception.
The register address, access type, and Reset state are:
Address
0xE000ED04
Access Read/write or read-only
Reset state
0x00000000
Figure 8-9 on page 8-20 shows the bit assignments of the Interrupt Control State
Register.
[19:16] Constant Reads as 0xF
[15:4] PARTNO Number of processor within family:
[11:10] b11 = Cortex family
[9:8] b00 = version
[7:6] b00 = reserved
[5:4] b10 = M (v7-M)
[3:0] X = family member. Cortex-M3 family is b0011.
[3:0] REVISION Implementation defined revision number.
Table 8-14 CPUID Base Register bit assignments (continued)
Bits Field Function

ARM Cortex-M3 Specifications

General

Architecture	ARMv7-M
Instruction Set	Thumb-2
Pipeline Stages	3-stage
Interrupts	Nested Vectored Interrupt Controller (NVIC)
Interrupt Controller	Nested Vectored Interrupt Controller (NVIC)
Memory Protection Unit	Optional
Power Consumption	Varies by implementation
Max Clock Speed	Up to 100 MHz
Debugging	JTAG and Serial Wire Debug (SWD)
Operating Voltage	1.8V to 3.6V
Manufacturing Process	Varies by implementation
Core Type	32-bit
