Core Debug
10-8 Copyright © 2005-2008 ARM Limited. All rights reserved. ARM DDI 0337G
Non-Confidential
Unrestricted Access
ICI can be written, though invalid values or when not used on an LDM/STM
causes a fault, as would on return from exception. Changing ICI from a value to
0 causes the underlying LDM/STM to start, not continue.
10.2.3 Debug Core Register Data Register
The purpose of the Debug Core Register Data Register (DCRDR) is to hold data for
reading and writing registers to and from the processor.
The DCRDR:
is a 32-bit read/write register
address
0xE000EDF8.
This is the data value written to the register selected by the Debug Register Selector
Register.
When the processor receives a request from the Debug Core Register Selector, this
register is read or written by the processor using a normal load-store unit operation.
If core register transfers are not being performed, software-based debug monitors can
use this register for communication in non-halting debug. For example, OS RSD and
Real View Monitor. This enables flags and bits to acknowledge state and indicate if
commands have been accepted to, replied to, or accepted and replied to.
10.2.4 Debug Exception and Monitor Control Register
The purpose of the Debug Exception and Monitor Control Register (DEMCR) is:
Vector catching. That is, to cause debug entry when a specified vector is
committed for execution.
Debug monitor control.
The DEMCR:
is a 32-bit read/write register
has address
0xE000EDFC.
Figure 10-2 on page 10-6 shows the bit assignments in the register.
