Clocking and Resets

Unrestricted Access Non-Confidential

Note

SWCLKTCK, DBGCLK, and TRACECLKIN only require to be driven if your

implementation contains Serial Wire JTAG Debug Port (SWJ-DP), Serial Wire Debug

Port (SW-DP), and TPIU blocks respectively. Otherwise, the clock inputs must be tied

off.

Note

The processor also contains a STCLK input. This port is not a clock. It is a reference

input for the SysTick counter, and it must be less than half the frequency of FCLK.

STCLK is synchronized internally by the processor to FCLK.
