ARM Cortex-M3 User Manual

System Debug
ARM DDI 0337G Copyright © 2005-2008 ARM Limited. All rights reserved. 11-31
Unrestricted Access Non-Confidential
Note
ITM registers are fully accessible in privileged mode. In user mode, all registers can be
read, but only the Stimulus Registers and Trace Enable Registers can be written, and
only when the corresponding Trace Privilege Register bit is set. Invalid user mode
writes to the ITM registers are discarded.
Trace Control Register Read/write 0xE0000E80 0x00000000 See ITM Trace Control Register on
page 11-34
Integration Write Write-only
0xE0000EF8 0x00000000 See ITM Integration Write Register on
page 11-35
Integration Read Read-only
0xE0000EFC 0x00000000 See ITM Integration Read Register on
page 11-36
Integration Mode Control Read/write
0xE0000F00 0x00000000 See ITM Integration Mode Control Register
on page 11-36
Lock Access Register Write-only
0xE0000FB0 0x00000000 See ITM Lock Access Register on page 11-37
Lock Status Register Read-only
0xE0000FB4 0x00000003 See ITM Lock Status Register on page 11-37
PID4 Read-only
0xE0000FD0 0x00000004 Val ue 0x04
PID5 Read-only 0xE0000FD4 0x00000000 Val ue 0x00
PID6 Read-only 0xE0000FD8 0x00000000 Val ue 0x00
PID7 Read-only 0xE0000FDC 0x00000000 Val ue 0x00
PID0 Read-only 0xE0000FE0 0x00000001 Val ue 0x01
PID1 Read-only 0xE0000FE4 0x000000B0 Val ue 0xB0
PID2 Read-only 0xE0000FE8 0x0000002B Val ue 0x2B
PID3 Read-only 0xE0000FEC 0x00000000 Val ue 0x00
CID0 Read-only 0xE0000FF0 0x0000000D Val ue 0x0D
CID1 Read-only 0xE0000FF4 0x000000E0 Val ue 0xE0
CID2 Read-only 0xE0000FF8 0x00000005 Val ue 0x05
CID3 Read-only 0xE0000FFC 0x000000B1 Val ue 0xB1
Table 11-19 ITM register summary (continued)
Name Type Address Reset value Description

ARM Cortex-M3 Specifications

General

Architecture	ARMv7-M
Instruction Set	Thumb-2
Pipeline Stages	3-stage
Interrupts	Nested Vectored Interrupt Controller (NVIC)
Interrupt Controller	Nested Vectored Interrupt Controller (NVIC)
Memory Protection Unit	Optional
Power Consumption	Varies by implementation
Max Clock Speed	Up to 100 MHz
Debugging	JTAG and Serial Wire Debug (SWD)
Operating Voltage	1.8V to 3.6V
Manufacturing Process	Varies by implementation
Core Type	32-bit
