ARM Cortex-M3 User Manual

Trace Port Interface Unit
ARM DDI 0337G Copyright © 2005-2008 ARM Limited. All rights reserved. 17-9
17.2.2 Description of the TPIU registers
This section describes the TPIU registers.
Supported Sync Port Sizes Register
This register is read/write. Each bit location represents a single port size that is
supported on the device, that is, 4, 2 or 1 in bit locations [3:0]. If the bit is set then that
port size is permitted. By default the RTL is designed to support all port sizes, set to
0x0000000B . This register is constrained by the input tie-off MAXPORTSIZE. The
external tie-off, MAXPORTSIZE, must be set during finalization of the ASIC to
reflect the actual number of TRACEDATA signals wired to physical pins. This is to
ensure that tools do not attempt to select a port width that an attached TPA cannot
capture. The value on MAXPORTSIZE causes bits within the Supported Port Size
register that represent wider widths to be clear, that is, unsupported.
Device ID register Read only 0xE0040FC8 0xCA0 (ETM
present)
0XCA1 (ETM
not present)
page 17-20
PID4 Read only
0xE0040FD0 0x04 -
PID5 Read only
0xE0040FD4 0x00 -
PID6 Read only
0xE0040FD8 0x00 -
PID7 Read only
0xE0040FDC 0x00 -
PID0 Read only
0xE0040FE0 0x23 -
PID1 Read only
0xE0040FE4 0xB9 -
PID2 Read only
0xE0040FE8 0x2B -
PID3 Read only
0xE0040FEC 0x00 -
CID0 Read only
0xE0040FF0 0x0D -
CID1 Read only
0xE0040FF4 0x90 -
CID2 Read only
0xE0040FF8 0x05 -
CID3 Read only
0xE0040FFC 0xB1 -
Table 17-5 TPIU registers (continued)
Name of register Type Address Reset value Page

ARM Cortex-M3 Specifications

General

Architecture	ARMv7-M
Instruction Set	Thumb-2
Pipeline Stages	3-stage
Interrupts	Nested Vectored Interrupt Controller (NVIC)
Interrupt Controller	Nested Vectored Interrupt Controller (NVIC)
Memory Protection Unit	Optional
Power Consumption	Varies by implementation
Max Clock Speed	Up to 100 MHz
Debugging	JTAG and Serial Wire Debug (SWD)
Operating Voltage	1.8V to 3.6V
Manufacturing Process	Varies by implementation
Core Type	32-bit
