ARM Cortex-M3 User Manual

Instruction Timing
18-4 Copyright © 2005-2008 ARM Limited. All rights reserved. ARM DDI 0337G
Non-Confidential
Unrestricted Access
Shift operations 32 1 ASR{S}, LSL{S}, LSR{S}, ROR{S}, and RRX{S}.
Miscellaneous 32 1 REV, REV16, REVSH, RBIT, CLZ, SXTB, SXTH,
UXTB, and UXTH. Extension instructions same as
corresponding ARM v6 16-bit instructions.
Table Branch 16
4+P
a
Table branches for switch/case use. These are LDR with
shifts and then branch.
Multiply 32 1 or 2 MUL, MLA, and MLS. MUL is one cycle and MLA and
MLS are two cycles.
Multiply with
64-bit result
32
3-7
c
UMULL, SMULL, UMLAL, and SMLAL. Cycle count
based on input sizes. That is, ABS(inputs) < 64K
terminates early.
Load-store
addressing
32 - Supports Format PC+/-imm12, Rbase+imm12,
Rbase+/-imm8, and adjusted register including shifts. T
variants used when in Privilege mode.
Load-store Single 32
2
b
(+P
a
if PC is destination)
LDR, LDRB, LDRSB, LDRH, LDRSH, STR, STRB, and
STRH, and T variants. PLD and PLI are both hints and so
act as a NOP.
Load-store
Multiple
32
1+N
b
(+P
a
if PC is loaded)
STM, LDM, LDRD, and STRD.
Load-store Special 32
1+N
b
LDREX, STREX, LDREXB, LDREXH, STREXB,
STREXH, CLREX. These fault if no local monitor (is IMP
DEF). LDREXD and STREXD are not included in this
profile.
Branches 32
1+P
a
B, BL, and B<cond>. No BLX (1) because it always
changes state. No BXJ.
System 32 1-2 MSR(2) and MRS(2) replace MSR/MRS but also do more.
These access the other stacks and also the status registers.
CPSIE/CPSID 32-bit forms are not supported.
No RFE or SRS.
System 16 1-2 CPSIE and CPSID are quick versions of MSR(2)
instructions and use the standard Thumb encodings, but
only permit use of i and f and not a.
Extended32 32 1 NOP and YIELD (hinted NOP). No MRS (1), MSR (1), or
SUBS (PC return link).
Table 18-1 Instruction timings (continued)
Instruction type Size Cycles count Description

ARM Cortex-M3 Specifications

General

Architecture	ARMv7-M
Instruction Set	Thumb-2
Pipeline Stages	3-stage
Interrupts	Nested Vectored Interrupt Controller (NVIC)
Interrupt Controller	Nested Vectored Interrupt Controller (NVIC)
Memory Protection Unit	Optional
Power Consumption	Varies by implementation
Max Clock Speed	Up to 100 MHz
Debugging	JTAG and Serial Wire Debug (SWD)
Operating Voltage	1.8V to 3.6V
Manufacturing Process	Varies by implementation
Core Type	32-bit
