Table 41 SATISFACTORY PRESSURES FOR THE OPERATION OF CRIMP TOOL HEADS (Continued)
Crimp Tool Head
Pressure
(psi)
Supplier Part Number Minimum Maximum
Thomas & Betts
13642 9500 10000
13642M 9500 10000
TBM12 9500 10000
WARNING
IF THE PRESSURE OF THE POWER PUMP IS MORE THAN THE MAXIMUM
PRESSURE PERMITTED FOR THE CRIMP TOOL HEAD, AN INJURY TO
PERSONNEL CAN OCCUR.
CAUTION
IF THE PRESSURE OF THE POWER PUMP IS MORE THAN THE MAXIMUM
PRESSURE PERMITTED FOR THE CRIMP TOOL HEAD, DAMAGE TO THE
CRIMP TOOL HEAD CAN OCCUR.
CAUTION
IF THE PRESSURE OF THE POWER PUMP IS LESS THAN THE MINIMUM
PRESSURE PERMITTED FOR THE CRIMP TOOL HEAD, THE CRIMP
CONNECTION OF THE TERMINAL LUG AND THE WIRE IS NOT
SATISFACTORY.
B. Crimp Tools with an Insulation Crimp Adjustment
The insulation crimp part of the hand crimp tool has three positions:
• 1 for a tight crimp
• 2 for a medium crimp
• 3 for a loose crimp.
It is necessary to test each combination of a tool, a terminal lug, and a wire to find the correct
adjustment:
(1) Set the adjustment to the loose position.
(2) Put a terminal lug in the crimp jaw of the crimp tool.
(3) Push the end of the wire into the insulation grip of the terminal lug until it stops.
Make sure that:
• The insulation is not removed from the end of the wire
• The end of the wire insulation is against the forward end of the insulation grip of the terminal
lug
• The wire insulation does not go into the crimp barrel of the terminal lug.
(4) Crimp the terminal lug.
(5) Examine the insulation support.
(6) Bend the wire back and forward once to make sure that the wire does not come out of the
terminal lug.
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-11
Page 47
Oct 15/2017D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
