Table 7 CABLE PREPARATION - SPECIAL CONFIGURATIONS (Continued)
Splice Kit Group Cable Configuration Special Instructions Cable Preparation
P4N1
2 Class 1 Cables
Fold the conductors back
Paragraph 4.N.
AWG 16 Conductor
2 Class 1 Cables
-
AWG 12 and AWG 16
Conductors
B. Splice Assembly Cable Preparation
(1) Make a selection of a splice assembly configuration from Table 7.
NOTE: Table 7 gives the special configurations of cable preparation.
For the configuration of the wires on each side of the splice assembly, refer to Table 2.
(2) If the wiring configuration and the splice kit are not specified in Table 7, make a selection of a
splice assembly configuration from Table 6.
NOTE: Table 6 gives the standard configurations of cable preparation.
For the configuration of the wires on each side of the splice assembly, refer to Table 2.
(3) If one build-up sleeve is specified, put a 1.0 inch ±0.1 inch length of the specified sleeve on the
applicable wiring. Refer to Table 5.
(4) If two build-up sleeves are specified, put the specified sleeves on the applicable wiring. Refer to
Table 5.
(a) Put a 0.9 inch ±0.1 inch length of the larger sleeve on the wiring.
(b) Put a 1.0 inch ±0.1 inch length of the other sleeve on the wiring.
(5) Prepare the end of each cable.
Refer to:
The applicable splice assembly configuration
Subject 20-00-15 for the procedure to remove the cable jacket
Subject 20-00-15 for the procedure to remove the wire insulation.
(6) If it is specified, fold the conductor or conductors back.
(7) If it is specified, fold the shield back.
CAUTION
DO NOT FOLD A SHIELD THAT HAS FLAT CONDUCTORS. DAMAGE TO
THE SHIELD CAN OCCUR.
(8) If a filler wire is specified:
(a) Cut a 1.0 inch to 2.0 inch length of the filler wire.
(b) Remove 0.30 inch ±0.05 inch of the insulation from the end of the wire. Refer to
Subject 20-00-15.
ASSEMBLY OF BACS52P SERIES AND D-150-0300 SERIES SHIELDED SPLICE ASSEMBLIES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-20
Page 69
Jun 15/2021D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
