Boeing 707 - Conductor Splice Part Numbers; Splice Assembly Wiring Build-Up Sleeves

Table 3 SHIELDED SPLICE KIT COMPONENT PART NUMBERS (Continued)
Splice Kit
Kit Component
Type Part Number Quantity Supplier
D-150-0376
Conductor Splice BACS52K3N 3 Tyco
Shield Material D-096-22-03-03 1 Tyco
Sleeve, Outer D-098-93-36-01 1 Tyco
Sleeve, Seal D-098-93-33-01 3 Tyco
Solder Sleeve SO96-4-00 2 Tyco
D-150-0377
Conductor Splice BACS52K3N 2 Tyco
Shield Material D-096-22-03-03 1 Tyco
Sleeve, Outer D-098-93-36-01 1 Tyco
Sleeve, Seal D-098-93-33-01 2 Tyco
Solder Sleeve SO96-3-00 1 Tyco
Solder Sleeve SO96-4-00 1 Tyco
C. Conductor Splice Part Numbers
Table 4
CONDUCTOR SPLICE PART NUMBERS
Part Number Crimp Barrel Size Color Code Supplier
323756 10-12 - Tyco
BACS52K1N 26-20 Red Tyco
D-094-05-10-12-02 20-16 Blue Tyco
BACS52K2N 20-16 Blue Tyco
BACS52K3N 16-12 Yellow Tyco
D. Splice Assembly Wiring Build-Up Sleeves
Table 5
WIRING BUILD-UP SLEEVES
Splice Kit
One Side of Splice Assembly Other Side of Splice Assembly
Wiring
Build-Up
Sleeve
Wiring Build-Up Sleeve
BACS52P1N1 BMS13-60T17C01G020 - BMS13-60T50C01G024 WTF1204
BACS52P1N1 BMS13-60T17C01G020 - BMS13-60T52C01G022 WTF1204
BACS52P1N1 BMS13-60T17C01G022 WTF1204 BMS13-60T52C01G020 WTF1204
BACS52P1N1 BMS13-60T17C01G022 WTF1204 BMS13-60T52C01G022 WTF1204
BACS52P1N1 BMS13-60T50C01G024 WTF1204 BMS13-60T17C01G020 -
BACS52P1N1 BMS13-60T50C01G024 WTF1204
BMS13-60T50C01G024
-
BMS13-60T50C01G024
ASSEMBLY OF BACS52P SERIES AND D-150-0300 SERIES SHIELDED SPLICE ASSEMBLIES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-20
Page 37
Jun 15/2021D6-54446
