1. GENERAL DATA
Refer to:
• Subject 20-14-11 for the repair of 777 flight control cables
• Subject 20-30-13 for the assembly of AMP/Tyco and BACS52N Copalum splices
• Subject 20-30-19 for the assembly of BACS52R shielded splices
• Subject 20-30-20 for the assembly of BACS52P and D-150-0300 series shielded splice assemblies
• Subject 20-30-21 for the assembly of BACS52T shielded splices.
• Subject 20-30-22 for the assembly of terminals and splices under special conditions.
A. Applicable Conditions for the Assembly of Splices
For the conditions that are applicable for:
• The repair of a wire or cable, refer to Subject 20-10-13
• The repair of a splice assembly, refer to Subject 20-10-13
• The assembly of a wire harness that has a splice, refer to Subject 20-10-11
• The installation of a wire harness that has a splice, refer to Subject 20-10-11.
For the assembly of:
• A splice that connects aluminum wires or an aluminum wire to a copper wire, refer to
Subject 20-30-13
• A specified splice, refer to Paragraph 1.B.
• A closed end splice, refer to Paragraph 5.A.
• An unsealed butt splice, refer to Paragraph 6.A.
• A sealed splice, refer to Paragraph 1.C.
B. Assembly of Specified Splices
Table 1 gives the location of the assembly procedure or the selection of the assembly procedure for the
applicable splice assembly configuration of a specified splice.
Table 1
ASSEMBLY PROCEDURES FOR SPECIFIED SPLICES
Specified Splice Supplier Splice Assembly Configuration Reference
34137 Tyco/AMP
Sealed Closed End Splice Paragraph 5.C.
Unsealed Closed End Splice Paragraph 5.E.
34138 Tyco/AMP
Sealed Closed End Splice Paragraph 5.C.
Unsealed Closed End Splice Paragraph 5.E.
48-7190 Amphenol Removable Pin Contact Splice Plug Paragraph 17.
48-7190-1 Amphenol Removable Pin Contact Splice Plug Paragraph 17.
48-7191 Amphenol Removable Socket Contact Splice Receptacle Paragraph 17.
48-7191-1 Amphenol Removable Socket Contact Splice Receptacle Paragraph 17.
BACS52L1N1 Boeing
Sealed Butt Splice Kit (Nickel) - One to Two
Wires
Paragraph 7.G.
BACS52L1T1 Boeing Sealed Butt Splice Kit - One to Two Wires Paragraph 7.G.
