Boeing 707 - Sealed Splice Configurations for Shielded Wire and Cable - Solder Shield Splice Kit - Four Shielded Wires to Four Shielded Wires

Table 112
CABLE TRIM DIMENSIONS
Cable Conductor
Trim Dimension
(inch)
Dimension Target Tolerance
A C1
D1 0.28
±0.02D2 0.70
D3 1.08
B C1
D1 0.28
±0.02D2 0.70
D3 1.08
C C1
D1 0.28
±0.02D2 0.70
D3 1.08
D C1
D1 0.28
±0.02D2 0.70
D3 1.08
E C1
D1 0.28
±0.02D2 0.70
D3 1.08
F C1
D1 0.28
±0.02D2 0.70
D3 1.08
F. Sealed Splice Configurations for Shielded Wire and Cable - Solder Shield Splice Kit - Four
Shielded Wires to Four Shielded Wires
Table 113
SPLICE KITS FOR FOUR SHIELDED WIRES TO FOUR SHIELDED WIRES
Jacket Maximum
O.D.
Shield Minimum
O.D.
Conductor CAU Range Solder Shield Splice Kit
Minimum Maximum Part Number Supplier
0.18 0.10 19 67 D-150-0285 Tyco/Raychem
ASSEMBLY OF SPLICES
