Table 2
PHASE IDENTIFICATION SLEEVES FOR TEMPERATURE GRADES C AND D
Area
Temperature
Range
(Degrees F)
Phase Identification
Sleeve
Supplier Phase
Phase Identification
Color Mark
Greater than or
equal to 275
AMS-DTL-23053/12-2()-2 QPL A Red -
AMS-DTL-23053/12-2()-4 QPL B Yellow -
AMS-DTL-23053/12-2()-6 QPL C Blue -
Raychem HT-SCE (Tape for
wire identification)
Raychem
A - Phase A
B - Phase B
C - Phase C
GENCOTE 125C (Protective
Sleeve)
General Plastics Corp.
A - Phase A
B - Phase B
C - Phase C
BEN-HAR 1151-FRB
(Protective Sleeve)
Bentley-Harris (Federal-Mogul)
A - Phase A
B - Phase B
C - Phase C
PTFE Heat-Shrinkable
(Grade D, Class 1 Heat
Shrinkable Sleeve)
Refer to Subject 20-00-11.
A Red -
B Yellow -
C Blue -
NOTE: There are two options to identify the wire with phase identification sleeve:
• Option 1: Colored sleeves for temperature grades C and D are available in basic colors-red,
yellow, and blue. These can be installed on the wires to identify phase.
• Option 2: PTFE heat-shrinkable sleeve in natural color can be installed on the wires with phase
identification mark, Phase A, Phase, B, or Phase C, printed on a high temperature identification
sleeve. The sleeve is installed on top of the PTFE heat-shrinkable sleeve or adjacent to the
sleeve.
2. GENERAL CONDITIONS FOR THE INSTALLATION OF TERMINALS
A. General Data
Insulation of these wires is necessary before any system is energized:
• The end of a wire that has no termination
• The end of a wire that has a terminal, but is not connected.
Refer to Subject 20-30-11 for the assembly of terminals to wire.
Refer to Subject 20-20-14 for the attachement of the terminals of the BACC13AU, BACC13AW and
BACC13AY Current Return Network cables to equipment or structure.
These conditions are applicable:
• A minimum of 1-1/2 threads of the stud or the screw must go through the end of the nut
• The size of the stud hole in the terminal lug must be the same as the size of the stud.
ELECTRICAL CONNECTION OF EQUIPMENT AND INSTALLATION OF TERMINAL LUGS
