Boeing 707 - Selection of a Sealed Splice Configuration

Table 1 ASSEMBLY PROCEDURES FOR SPECIFIED SPLICES (Continued)
Specified Splice Supplier Splice Assembly Configuration Reference
NAS1387-() QPL
Butt Splice With Sleeve - One Wire Paragraph 6.D.
Butt Splice With Sleeve - More Than One Wire Paragraph 6.E.
NAS1388-() QPL
Insulated Butt Splice - One Wire Paragraph 6.B.
Insulated Butt Splice - More Than One Wire Paragraph 6.C.
NAS1389-() QPL
Insulated Butt Splice - One Wire Paragraph 6.B.
Insulated Butt Splice - More Than One Wire Paragraph 6.D.
C. Selection of a Sealed Splice Configuration
For the applicable splice assembly configurations for:
• Unshielded wire and unshielded cable, refer to Table 2
• Shielded wire and shielded cable, refer to Table 3.
Table 2
SEALED SPLICE CONFIGURATIONS FOR UNSHIELDED WIRE AND UNSHIELDED CABLE
Maximum Temperature Grade
Wire Size
(AWG)
Reference
Minimum Maximum
B 24 2 Paragraph 7.A.
D
24 10 Paragraph 8.A.
8 2/0 Subject 20-30-13
ASSEMBLY OF SPLICES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-12
Page 9
Oct 15/2017D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
