Boeing 707 - Insulated Butt Splices

Table 9
SLEEVE PART NUMBERS FOR SEALED CLOSED END SPLICES
Parallel Splice
Maximum Number
of Wires
Sleeve
Part Number
Number of Holes in
Wire Seal
Supplier
D-609-04
2
D-436-0098 1 Tyco/Raychem
D-436-45 1 Tyco/Raychem
D-436-73 1 Tyco/Raychem
5 D-436-46 5 Tyco/Raychem
D-609-05
2
D-436-0098 1 Tyco/Raychem
D-436-45 1 Tyco/Raychem
D-436-73 1 Tyco/Raychem
5 D-436-46 5 Tyco/Raychem
34137
2
D-436-0098 1 Tyco/Raychem
D-436-45 1 Tyco/Raychem
D-436-73 1 Tyco/Raychem
DWP-125 1 Tyco/Raychem
MWSF 1 Remtek
5 D-436-46 5 Tyco/Raychem
34138
2
D-436-73 1 Tyco/Raychem
DWP-125 1 Tyco/Raychem
MWSF 1 Remtek
4 D-436-48 4 Tyco/Raychem
5 D-436-46 5 Tyco/Raychem
B. Insulated Butt Splices
Table 10
PART NUMBERS OF INSULATED BUTT SPLICES
CAU Range
Part Number
Crimp Barrel
Size
Description
Insulation
Color
Supplier
Minimum Maximum
3 8 NAS1388-5 26-22 Insulation Grip Yellow QPL
4 12 NAS1388-4 24-20 Insulation Grip White QPL
7 24 NAS1388-1 22-18 Insulation Grip Red QPL
15 51 NAS1388-2 16-14 Insulation Grip Blue QPL
59 138 NAS1388-3 12-10 Insulation Grip Yellow QPL
132 208 NAS1389-1 8 No Insulation Grip Red QPL
209 331 NAS1389-4 6 No Insulation Grip Blue QPL
332 526 NAS1389-7 4 No Insulation Grip Yellow QPL
ASSEMBLY OF SPLICES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-12
Page 16
Oct 15/2017D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
