Table 6
COMPONENT PART NUMBERS OF SEALED CLOSED END SPLICE KITS
Splice Kit Component Part Number Crimp Barrel Size Color Strip Supplier
D-436-58
Parallel Splice D-609-04 20-16 Blue Tyco/Raychem
Sleeve D-436-45 - - Tyco/Raychem
D-436-59
Parallel Splice D-609-05 16-12 Yellow Tyco/Raychem
Sleeve D-436-45 - - Tyco/Raychem
D-436-60
Parallel Splice D-609-04 20-16 Blue Tyco/Raychem
Sleeve D-436-46 - - Tyco/Raychem
D-436-61
Parallel Splice D-609-05 16-12 Yellow Tyco/Raychem
Sleeve D-436-46 - - Tyco/Raychem
D-436-99
Parallel Splice D-609-14 16-12 Yellow TE
Sleeve D-436-94 - - TE
D-436-0129
Parallel Splice 34138 12-10 - Tyco/AMP
Sleeve D-436-48 - - Tyco/Raychem
Table 7
PART NUMBERS OF INSULATED CLOSED END SPLICES
CAU Range
Part Number Crimp Barrel Size Supplier
Minimum Maximum
20 52 35115 22-14 Tyco/AMP
32 131 35653 18-10 Tyco/AMP
Table 8
PART NUMBERS OF PARALLEL SPLICES
CAU Range
Part Number Crimp Barrel Size Color Stripe Supplier
Minimum Maximum
8 27 D-609-04 20-16 Blue Tyco/Raychem
15 51 34137 16-14 - Tyco/AMP
19 67 D-609-05 16-12 Yellow Tyco/Raychem
19 67 D-609-14 16-12 Yellow TE
43 138 34138 12-10 - Tyco/AMP
ASSEMBLY OF SPLICES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-12
Page 15
