• The end of the conductor extends farther than the end of the crimp barrel
• The maximum distance from the end of the wire insulation of a single wire to the end of the
crimp barrel is 0.12 inch for AWG 10 and smaller, and 0.25 inch for AWG 8 and larger
• The clearance from the end of the conductor is sufficent for the installation of the washer
and the nut.
F. Assembly of BACT12AR and Other Restrictive Entry Terminal Lugs
Refer to Paragraph 1.D. for the description of the BACT12AR terminal lugs.
Table 56
CRIMP TOOLS FOR BACT12AR TERMINAL LUGS
Wire Size
Terminal Lug Crimp Tool
Crimp
Barrel
Size
Sleeve
Color
Band
Color
Basic Unit Holder Head Die
26 24 Yellow Blue 59275 - - -
- - - -
47907-() - - -
565435-5 - 567200-2 69878
59275 - - -
68075 - - 69878
69692-1 - - -
69875 - - 69878
22 22 Red Green
189721-1 356303-1 - 314270-1
314423-() - -
314270-1
314270-2
314597-() - -
314270-1
314270-2
46110 - - -
4B2-457540-6 - 687658-1 69872
59250 - - -
68075 - - 69872
69004 - - 47451
69005 - 47516 -
69118-() - - 45185-7
69365-() - - 47806-2
69875 - - 69872
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-11
Page 62
Oct 15/2017D6-54446
