Boeing 707 - Kit Group P1 N2 - One Class 2 Cable and One Class 1 Cable to Two Class 1 Cables

F. Kit Group P1N2 - One Class 2 Cable and One Class 1 Cable to Two Class 1 Cables
Refer to Figure 12.
Table 14
CONNECTIONS
Wire Connection Wires Connected to
A1 and B1 Splice C1
A2 Splice D1
2449578 S00061545739_V1
ONE CLASS 2 CABLE AND ONE CLASS 1 CABLE TO TWO CLASS 1 CABLES
Figure 12
ASSEMBLY OF BACS52P SERIES AND D-150-0300 SERIES SHIELDED SPLICE ASSEMBLIES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-20
Page 87
Jun 15/2021D6-54446
