Table 52
CAU OF THE DIFFERENT BAC3108 SHIELDS
Shield Part Number CAU of the Shield
An Applicable Terminal Crimp Barrel
Size
BAC3108-1B 6 18-22
BAC3108-1D 12 18-22
BAC3108-1E 18 16-14
BAC3108-1G 24 16-14
BAC3108-1 30 16-14
BAC3108-2C 42 16-14
BAC3108-2B 60 12-10
BAC3108-2E 76 12-10
BAC3108-2F 77 12-10
BAC3108-2 96 12-10
BAC3108-3 96 12-10
BAC3108-3D 96 12-10
BAC3108-4 132 8
(1) Make shield ground wire from the end of the shield of the cable or shielded wire.
Refer to Subject 20-10-15 for the assembly of a shield ground wire with a shield pull-through.
(2) Find the CAU of the shield.
Refer to:
• Table 42 for the table that has the CAU data for the shielded wire or cable
• Table 52 for the CAU data for the different BAC3108 shields.
(3) Make a selection of a terminal lug.
Use the CAU of the shield and the stud hole size to make the selection.
(4) Assemble the terminal lug. Refer to the paragraph applicable to the assembly of the terminal lug.
D. Assembly of BACT12AC Terminal Lugs
Refer to Paragraph 1.B. for the description of the BACT12AC terminal lugs.
Table 53
CRIMP TOOLS FOR SMALL BACT12AC TERMINAL LUGS
Crimp
Barrel Size
Insulation
Color
Crimp Tool
Special
Instructions
Basic Unit Holder Head Die
26-24 Yellow 59275 - - - -
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-11
Page 55
Feb 15/2016D6-54446
