Table 12 BACT12E 90 DEGREE UPRIGHT TERMINAL LUG PART NUMBERS (Continued)
Crimp Barrel Size
(Wire Size Range)
(AWG)
CAU Range
Stud Hole Size Boeing Standard
Minimum Maximum
4/0 1666 2257
3/8 BACT12E401
1/2 BACT12E402
Table 13
SUPPLIER PART NUMBERS FOR BACT12E TERMINAL LUGS
Boeing Standard Part Number Supplier
BACT12E10
C26U Thomas & Betts
YAV10-R Burndy
BACT12E101 YAV25-RS Burndy
BACT12E102 YAV25-RS3 Burndy
BACT12E11 YAV10-R3 Burndy
BACT12E14
B-36U Thomas & Betts
YAV14-R Burndy
BACT12E18
A-36U Thomas & Betts
YAV18-R Burndy
BACT12E2 YAV2C-RS Burndy
BACT12E201 YAV26-RS Burndy
BACT12E300 YAV27-RS Burndy
BACT12E4 YAV4C-RS Burndy
BACT12E401 YAV28-RS Burndy
BACT12E402 YAV28-RS12 Burndy
BACT12E6 YAV6C-RS Burndy
BACT12E81 YAV8C-RS Burndy
G. BACT12G and Burndy YBM Series Flag Terminal Lugs
Refer to Paragraph 2.K. for the procedure to assemble these terminals.
BACT12G and Burndy YBM Series flag terminal lugs:
• Are not insulated
• Have no wire insulation grip.
