TABLE OF CONTENTS
PARAGRAPH PAGE
1. PART NUMBERS AND DESCRIPTION 2
A. AMP Copalum Terminal Part Numbers 2
B. BACT12AW, BACT12AY, and BACT13K, BACT13L, BACT13T Copalum Terminal Part
Numbers 8
C. MS25435 and Thomas & Betts Aluminum Terminal Part Numbers 13
2. TERMINAL ASSEMBLY
14
A. Wire Preparation for AMP Copalum Terminals and Aluminum Terminals 14
B. Wire Preparation for BACT12AW and BACT12AY Copalum Terminals 15
C. Wire Preparation for BACT13K Copalum Terminals 16
D. Wire Preparation for BACT13L Copalum Terminals 19
E. Wire Preparation for BACT13T Copalum Terminals 21
F. Selection of an Insulation Sleeve 22
G. Assembly of Tyco/AMP Copalum Terminals and Aluminum Terminals 23
H. Assembly of BACT12AW, BACT12AY, BACT13K, BACT13L, and BACT13T Copalum
Terminals 27
I. Insulation of the Terminal Lug Assembly 33
J. Extension of the Terminal Lug Assembly Insulation - Standard Configuration 35
K. Extension of the Terminal Lug Assembly Insulation - Special Configuration 36
L. Preparation of the Tyco 58422-1 Hydraulic Crimp Tool 38
M. Preparation of the Tyco 69066 Hydraulic Crimp Tool 41
N. Insulation of the Terminal Lug Assembly 44
3. APPROVED TOOL SUPPLIERS
47
A. Crimp Tools 47
707, 727-787
STANDARD WIRING PRACTICES MANUAL
ASSEMBLY OF AMP (TYCO) COPALUM, MS25435 AND THOMAS & BETTS ALUMINUM
TERMINALS
20-30-14
Page 1
Oct 15/2017D6-54446
