C. Assembly of the Conductor Splice
Table 8
CONDUCTOR SPLICE CRIMP TOOLS
Crimp Barrel Size
Crimp Tool
Type Basic Unit Die or Nest Color Supplier
26-20
Hand
AD-1377 Red Tyco
ST956C Red Boeing
ST956D Red Boeing
Power PMTB-232 Red Daniels
20-16
Hand
AD-1377 Blue Tyco
ST956C Blue Boeing
ST956D Blue Boeing
Power PMTB-232 Blue Daniels
16-12
Hand
AD-1377 Yellow Tyco
ST956C Yellow Boeing
ST956D Yellow Boeing
Power PMTB-232 Yellow Daniels
12-10 Hand 46447 12-10 AMP
(1) Make a selection of a crimp tool from Table 8.
(2) Assemble the conductor splice.
Refer to:
• The applicable cable preparation configuration
• Paragraph 5.A. for the procedure to assemble the conductor splice.
(3) Align the center of the seal sleeve with the center of the splice assembly.
(4) Shrink the sleeve into its position. Refer to Subject 20-10-14 for the procedure to shrink a heat
shrinkable sleeve
NOTE: If the sleeve has a tight fit on the conductor splice and cannot be moved on the
assembly, it is not necessary for the sleeve to shrink fully on the wire.
D. Assembly of the Shield Splice
(1) On one end of the splice assembly, align the end of the shield material with the end of the cable
jacket. Refer to Figure 3.
Make sure that:
• The end of the shield material is not farther than 0.04 inch from the end of cable jacket
• The shield material does not make an overlap with the cable jacket.
ASSEMBLY OF BACS52P SERIES AND D-150-0300 SERIES SHIELDED SPLICE ASSEMBLIES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-20
Page 70
Jun 15/2021D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
