B. Circular Area Units of Terminals
Table 2
CAU OF TERMINALS
Crimp Barrel
Size
CAU Terminal
Minimum Maximum Type
Specification or
Standard
Description
26 2 3 Insulated BACT12AR() With Insulation Grip
26-22 3 8 Insulated BACT12AC() With Insulation Grip
24 4 5 Insulated BACT12AR() With Insulation Grip
22 6 8 Insulated BACT12AR() With Insulation Grip
22-18
7 24 Insulated BACT12AC() With Insulation Grip
5 20 Uninsulated
BACT12E() No Insulation Grip
BACT12G() No Insulation Grip
MS20659-() With Insulation Grip
20 8 11 Insulated BACT12AR() With Insulation Grip
18 12 18 Insulated BACT12AR() With Insulation Grip
16 19 26 Insulated BACT12AR() With Insulation Grip
16-14
15 51 Insulated BACT12AC() With Insulation Grip
21 42 Uninsulated
BACT12E() No Insulation Grip
BACT12G() No Insulation Grip
MS20659-() With Insulation Grip
14 27 41 Insulated BACT12AR() With Insulation Grip
12 42 65 Insulated BACT12AR() With Insulation Grip
12-10
43 138 Insulated BACT12AC() With Insulation Grip
50 100 Uninsulated
BACT12E() No Insulation Grip
BACT12G() No Insulation Grip
MS20659-() With Insulation Grip
10 66 105 Insulated BACT12AR() With Insulation Grip
8
132 208 Insulated BACT12AC() With Insulation Grip
131 181 Uninsulated
BACT12E() No Insulation Grip
BACT12G() No Insulation Grip
BACT12M() No Insulation Grip
MS20659-() With Insulation Grip
ASSEMBLY OF TERMINALS AND SPLICES UNDER SPECIAL CONDITIONS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-22
Page 4
