Table 1 CAU OF CONDUCTORS (Continued)
Wire Size
(AWG)
Conductor
Type
Maximum O.D.
(inch)
CAU
20
Solid 0.032 12
Stranded 0.038 12
18
Solid 0.040 19
Stranded 0.046 19
16
Solid 0.051 24
Stranded 0.059 24
15
Solid 0.057 33
Stranded 0.065 33
14
Solid 0.064 38
Stranded 0.074 38
13
Solid 0.072 52
Stranded 0.082 52
12
Solid 0.081 59
Stranded 0.093 59
10
Solid 0.102 99
Stranded 0.117 99
8
Solid 0.129 170
Stranded 0.148 170
6
Solid 0.162 268
Stranded 0.186 268
4
Solid 0.204 426
Stranded 0.235 426
2
Solid 0.258 665
Stranded 0.297 665
1
Solid 0.290 837
Stranded 0.328 837
1/0
Solid 0.352 1045
Stranded 0.374 1045
2/0
Solid 0.365 1330
Stranded 0.420 1330
3/0
Solid 0.410 1665
Stranded 0.472 1665
4/0
Solid 0.460 2109
Stranded 0.530 2109
