Boeing 707 - Assembly of MS20659 Terminal Lugs

N. Assembly of MS20659 Terminal Lugs
Refer to Paragraph 1.K. for the description of the MS20659 terminal lugs.
Table 67
CRIMP TOOLS FOR SMALL MS20659 TERMINAL LUGS
Crimp
Barrel Size
Crimp Tool
Basic Unit Head Die Set Nest Indenter Special Instructions
22 - 18
46673 - - - - -
49900 - - - - -
49935 - - - - -
Bandolug SME - S18HT - - -
M8ND - N14HT - -
Use for Burndy terminal lugs
only
Y8ND - N14HT - -
Use for Burndy terminal lugs
only
16 - 14
49900 - - - - -
49935 - - - - -
59294-() - - - - -
Bandolug SME - S14HT - - -
M8ND - N10HT - -
Use for Burndy terminal lugs
only
Y8ND - N10HT - -
Use for Burndy terminal lugs
only
12 - 10
46447 - - - - -
49900 - - - - -
49935 - - - - -
59461 - - - - -
M8ND - N10HT - -
Use for Burndy terminal lugs
only
Power Pump
Y34A - V8L 34PL -
Y34A - V8L 34PL-2 -
Y10MRF-4 - - - - -
Y10MRF-5 - - - - -
Y8ND - N10HT - -
Use for Burndy terminal lugs
only
