CAUTION
THE O.D. OF THE WIRE INSULATION IS VERY IMPORTANT. MAKE SURE
THAT FOR THE SPECIFIED SPLICE IN TABLE 1 OR TABLE 2, THE O.D OF
THE WIRE INSULATION IS NOT MORE THAN THE MAXIMUM O.D.
SPECIFIED.
CAUTION
IF THE O.D. OF THE WIRE IS LESS THAN THE MINIMUM O.D SPECIFIED,
THE O.D. OF THE INSULATION MUST BE INCREASED TO MAKE A SEAL
IN THE SPLICE.
(3) Remove the necessary length of the insulation from the end of each wire.
Refer to:
• Table 10
• Subject 20-00-15 for the insulation removal procedures.
Make sure that the end of each wire has not been crimped before.
(4) If the O.D. of the wire insulation is less than the minimum O.D. specified in Table 1 or Table 2,
increase the O.D. of the wire.
For the procedure to increase the O.D. of the wire insulation with:
• Layers of tape, refer to Paragraph 4.F.
• Heat shrinkable sleeves, refer to Paragraph 4.G..
D. Wire Preparation - Splices with other Wire Size Combinations
Table 11
INSULATION REMOVAL LENGTH
Splice
Removal Length
(inch)
Target Tolerance
277156-1 0.44 ±0.03
277157-1 0.50 ±0.03
277158-1 0.69 ±0.03
277159-1 0.75 ±0.03
277160-1 0.88 ±0.03
277161-1 1.00 ±0.03
277162-1 1.00 ±0.03
277163-1 1.00 ±0.03
277164-1 0.69 ±0.03
277165-1 0.69 ±0.03
277168-1 1.00 ±0.03
(1) Measure the O.D. of the wire insulation on each wire that must have a splice.
(2) Make a selection of one of these splices:
ASSEMBLY AND REPAIR OF THE AMP AND BACS52N COPALUM SPLICES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-13
Page 12
Oct 15/2017D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
