D. Splice Assembly Wiring Build-Up Sleeves
Table 3
WIRING BUILD-UP SLEEVES
Splice Kit Part
Number
Shield Splice End with Smaller Diameter Shield Splice End with Larger Diameter
Wire Part Number
Build-Up Sleeve
Part Number
Wire Part Number
Build-Up Sleeve
Part Number
BACS52R1T2 BMS13-80T01C02G024 - BMS13-80T01C02G024 M23053/5-106-4
BACS52R1T2 BMS13-80T01C02G026 - BMS13-80T01C02G026 M23053/5-105-4
BACS52R2T4 BMS13-80T02C02G022 M23053/5-106-4
BMS13-80T02C02G022
(Quantity 2)
-
BACS52R2T1 BMS13-48T38C01G020 - BMS13-48T38C01G018
M23053/5-105-4
and
M23053/5-106-4
BACS52R3T1 BMS13-48T12C01G016 M23053/5-106-4 BMS13-48T12C01G012 -
2. SPLICE ASSEMBLY
A. Selection of a Cable Preparation Procedure
Table 4
SPECIAL CABLE PREPARATION CONFIGURATIONS
Splice Kit
Wiring Configuration
One End of Conductor Splice Other End of Conductor Splice
BACS52R2T1
1 Cable, 1 AWG 16, AWG 18 or AWG 20 Conductor 1 Cable, 1 AWG 22 or AWG 24 Conductor
1 Cable, 1 AWG 22 Conductor
1 Cable, 1 AWG 24 Conductor
1 Cable, 1 AWG 22 Conductor
2 Cables, 1 AWG 22 Conductor 1 Cable, 1 AWG 22 Conductor
2 Cables, 1 AWG 24 Conductor 1 Cable, 1 AWG 24 Conductor
BACS52R2T2
1 Cable, 2 AWG 16, AWG 18 or AWG 20 Conductors 1 Cable, 2 AWG 22 or AWG 24 Conductors
2 Cables, 2 AWG 22 Conductors 1 Cable, 2 AWG 22 Conductors
BACS52R2T4
1 Cable, 2 AWG 22 or AWG 24 Conductors 1 Cable, 2 AWG 22 or AWG 24 Conductors
2 Cables, 2 AWG 22 or AWG 24 Conductors 1 Cable, 2 AWG 22 or AWG 24 Conductors
2 Cables, 2 AWG 26 Conductors 2 Cables, 2 AWG 26 Conductors
BACS52R3T1
1 Cable, 1 AWG 12 or AWG 14 Conductor 1 Cable, 1 AWG 18 or AWG 20 Conductor
2 Cables, 1 AWG 16, AWG 18 or AWG 20 Conductor 1 Cable, 1 AWG 18 or AWG 20 Conductor
BACS52R3T2
1 Cable, 2 AWG 12 Conductors 1 Cable, 2 AWG 20 Conductors
1 Cable, 2 AWG 14 Conductors 1 Cable, 2 AWG 20 Conductors
BACS52R3T3 2 Cables, 2 AWG 18 Conductors 1 Cable, 2 AWG 18 Conductors
BACS52R4T1
1 Cable, 1 AWG 10 Conductor 1 Cable, 1 AWG 16 Conductor
2 Cables, 1 AWG 14 Conductor 1 Cable, 1 AWG 14 conductor
ASSEMBLY OF BACS52R SHIELDED SPLICES
