Table 1 SPLICE KIT COMPONENT PART NUMBERS (Continued)
Splice Kit Component
Type Part Number Quantity
BACS52R3T3
Conductor Splice BACS52K3 2
Seal Sleeve BACS13CM3 2
Solder Shield Splice Sleeve BACS13DF7 1
BACS52R3T4
Conductor Splice BACS52K3 4
Seal Sleeve BACS13CM3 4
Solder Shield Splice Sleeve BACS13DF7 1
BACS52R3T5
Conductor Splice BACS52K3 1
Seal Sleeve BACS13CM6 1
Solder Shield Splice Sleeve BACS13DF3 1
BACS52R3T6
Conductor Splice BACS52K3 3
Seal Sleeve BACS13CM3 3
Solder Shield Splice Sleeve BACS13DF7 1
BACS52R4T1
Conductor Splice NAS1387-6 1
Seal Sleeve BACS13CM6 1
Solder Shield Splice Sleeve BACS13DF8 1
BACS52R4T2
Conductor Splice NAS1387-6 2
Seal Sleeve BACS13CM6 2
Solder Shield Splice Sleeve BACS13DF7 1
C. Conductor Splice Part Numbers
Table 2
CONDUCTOR SPLICE PART NUMBERS
Part Number Crimp Barrel Size Color Code
NAS1387-6 12-10 -
BACS52K1 26-20 Red
BACS52K2 20-16 Blue
BACS52K3 16-12 Yellow
ASSEMBLY OF BACS52R SHIELDED SPLICES
