Boeing 707 - Sealed Splice Configurations with Shield Termination Rings and Shield Terminator Bands for Shielded Wire and Shielded Cable for High Temperature; Splice Assembly Configurations

13. SEALED SPLICE CONFIGURATIONS WITH SHIELD TERMINATION RINGS AND SHIELD TERMINATOR
BANDS FOR SHIELDED WIRE AND SHIELDED CABLE FOR HIGH TEMPERATURE
A. Splice Assembly Configurations
NOTE: Temperature grade D Shield-Kons are no longer manufactured. The procedures in Paragraph
13.B., Paragraph 13.C., Paragraph 13.D., and Paragraph 13.E. replace Shield-Kon assembly
procedures for high temperature shielded splice applications.
For the conditions that are applicable for:
• The repair of a wire or a cable with a splice, refer to Subject 20-10-13
• The selection of the correct sealed splice configuration, refer to Paragraph 1.C..
Table 104
SPLICE ASSEMBLY CONFIGURATIONS
One End of Splice
Assembly
Other End of Splice
Assembly
Applicable
Condition
Splice Assembly
Configuration Procedure
One Shielded Wire One Shielded Wire
Fuel Vapor Tape, Ties Paragraph 13.B.
No Fuel Vapor
Tape, Sleeves Paragraph 13.C.
Tape, Ties Paragraph 13.B.
One Shielded Cable One Shielded Cable
Fuel Vapor Tape, Ties Paragraph 13.D.
No Fuel Vapor
Tape, Sleeves Paragraph 13.E.
Tape, Ties Paragraph 13.D.
