Boeing 707 - Terminal Receptacle Installation

CAUTION
DO NOT CHANGE THE SHAPE OF THE INSULATION BARREL OR WIRE
BARREL OF THE RECEPTACLE. THE WIRE WILL NOT GO INTO THE
RECEPTACLE CORRECTLY.
(6) Put the wire into the receptacle so that the end of the insulation is against the insulation stop.
(7) Close the handles tool of the until the ratchet releases.
B. Terminal Receptacle Installation
Table 4
TERMINAL RECEPTACLE INSERTION TOOLS
Insertion Tool Supplier
452383-1 AMP
(1) Make a selection of a Grade B, Class 1 heat shrinkable sleeve from Subject 20-00-11.
(2) Put a 0.60 inch length of the heat shrinkable sleeve on the wire.
(3) Make a selection of an insertion tool from Table 4.
(4) Put the insertion tool on the wire between the heat shrinkable sleeve and the receptacle.
(5) Move the insertion tool toward the end of the wire until it is against the rear end of the receptacle.
(6) Push the receptacle onto the pin until the ring on the inside of the receptacle is in the groove on
the pin. Refer to Figure 3.
AMP PRINTED CIRCUIT BOARD TERMINAL RECEPTACLES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-17
Page 5
Jun 15/2021D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
