Table 2
STANDARD STUD SIZES
Stud Size
Diameter
(inch)
2 0.086
4 0.112
5 0.125
6 0.138
8 0.164
10 0.190
1/4 0.250
5/16 0.312
3/8 0.375
7/16 0.438
1/2 0.500
5/8 0.625
3/4 0.750
7/8 0.875
B. BACT12AC General Purpose Terminal Lugs
Refer to Paragraph 2.D. for the procedure to assemble these terminals.
Some BACT12AC terminal lugs have an insulation grip. Some of the larger size BACT12AC terminal
lugs do not have an insulation grip.
BACT12AC insulated terminal lugs must be used:
• To terminate BMS 13-51 Grade B AWG 8 and larger wire
• To terminate BMS 13-48 AWG 8 and larger wire
• To terminate BMS 13-31 wire in Temperature Grade Zone A and Zone B.
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
