Boeing 707 - Selection of a Splice Assembly Configuration; Splice Assembly

Table 5 WIRING BUILD-UP SLEEVES (Continued)
Splice Kit
One Side of Splice Assembly Other Side of Splice Assembly
Wiring
Build-Up
Sleeve
Wiring Build-Up Sleeve
D-150-0355 BMS13-60T17C01G022
WTF1204 BMS13-60T17C01G022
-
WTF1205 BMS13-60T17C01G022
D-150-0355
BMS13-60T17C01G022
- BMS13-60T17C01G022
WTF1204
BMS13-60T17C01G022 WTF1205
D-150-0355 BMS13-60T49C04G020
WTF1205
BMS13-78T06C04G018 -
WTF1205
D-150-0355 BMS13-78T06C04G018 - BMS13-60T49C04G020
WTF1205
WTF1205
D-150-0356 BMS13-60T52C03G020
WTF1204
BMS13-78T05C03G016 -
WTF1205
D-150-0356 BMS13-60T52C03G020
WTF1204
BMS13-78T05C03G018 -
WTF1205
D-150-0356 BMS13-78T05C03G016 - BMS13-60T52C03G020
WTF1204
WTF1205
D-150-0356 BMS13-78T05C03G018 - BMS13-60T52C03G020
WTF1204
WTF1205
2. SPLICE ASSEMBLY
A. Selection of a Splice Assembly Configuration
For the conditions that are applicable for this section, refer to Paragraph 2.B..
Table 6
CABLE PREPARATION - STANDARD CONFIGURATIONS
Splice Kit Group
Quantity of
Conductor
Splices
Wiring Configuration
Cable Preparation
One End of the Splice Other End of the Splice
P1N1 1
One Class 1 Cable One Class 1 Cable Paragraph 3.A.
One Class 1 Cable One Class 2 Cable Paragraph 3.C.
One Class 1 Cable Two Class 1 Cables Paragraph 3.B.
One Class 2 Cable One Class 3 Cable Paragraph 3.D.
Two Class 1 Cables Two Class 1 Cables Paragraph 3.E.
ASSEMBLY OF BACS52P SERIES AND D-150-0300 SERIES SHIELDED SPLICE ASSEMBLIES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-20
Page 63
Jun 15/2021D6-54446
