This Subject gives the procedures:
• To assemble a copalum splice with stranded aluminum and stranded copper wire
• To repair the insulation of a copalum splice
• To replace a copalum splice.
1. GENERAL DATA
A. General Conditions
For the conditions that are applicable for the repair of wiring, refer to Subject 20-10-13.
B. Configuration of Splices on Adjacent Power Feeder Wires
These conditions are applicable:
• If more than one splice in a power feeder harness is necessary, the recommended configuration
is to install splices intervals along the longitudinal axis of the wire harness; refer to Figure 1
• If it is not possible to install the splices at intervals, the splices can make 100 percent overlap;
refer to Figure 2.
CONFIGURATION OF SPLICES AT INTERVALS
Figure 1
ASSEMBLY AND REPAIR OF THE AMP AND BACS52N COPALUM SPLICES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-13
Page 2
Oct 15/2015D6-54446
