Boeing 707 - Sealed Splice Configurations for Shielded Wire and Cable - Solder Shield Splice Kit - In-Line Resistor and Diode

Table 138
CABLE TRIM DIMENSIONS
Cable Conductor
Trim Dimension
(inch)
Dimension Target Tolerance
A
C1
D1 0.28
±0.02D2 1.92
D3 2.20
C2
D1 0.28
±0.02D2 1.92
D3 2.20
C3
D1 0.28
±0.02D2 0.77
D3 1.05
C4
D1 0.28
±0.02D2 0.77
D3 1.05
B
C1
D1 0.28
±0.02D2 1.92
D3 2.20
C2
D1 0.28
±0.02D2 1.92
D3 2.20
C3
D1 0.28
±0.02D2 0.77
D3 1.05
C4
D1 0.28
±0.02D2 0.77
D3 1.05
S. Sealed Splice Configurations for Shielded Wire and Cable - Solder Shield Splice Kit - In-Line
Resistor and Diode
(1) Assemble in-line resistors and diodes to shielded cable in accordance with Figure CCC, Table
DDD and as follows:
ASSEMBLY OF SPLICES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-12
Page 330
Jun 15/2021D6-54446
