(c) Crimp the terminal lug again.
Make sure that the second crimp is in the same location along crimp barrel as the first
crimp.
(10) If the terminal is a Thermo-Electric thermocouple terminal lug part number 1387-3 or 1387-4:
(a) Make a selection of a flux and a high temperature silver/lead solder. Refer to
Subject 20-00-11.
(b) Solder the terminal lug to the conductor.
(11) If a length of heat shrinkable sleeve is on the wire, shrink it into its position on the end of the wire
insulation.
NOTE: The heat shrinkable sleeve keeps the strands of the insulation braid together.
3. APPROVED TOOL SUPPLIERS
A. Crimp Tools
Table 84
CRIMP TOOL SUPPLIERS
Tool Description Supplier
11732 Crimp Die Thomas & Betts
11734 Crimp Die Thomas & Betts
11737 Crimp Die Thomas & Betts
11738 Crimp Die Thomas & Betts
11739 Crimp Die Thomas & Betts
1213875-1 Power Hand Crimp Tool Tyco/Amp
13597 Power Pump Thomas & Betts
13600 Power Crimp Tool Thomas & Betts
13642 Power Crimp Tool Thomas & Betts
13642M Head Thomas & Betts
1490413-1 Nest Tyco/Amp
1490413-2 Nest Tyco/Amp
1490413-3 Nest Tyco/Amp
1490413-4 Nest Tyco/Amp
1490413-5 Nest Tyco/Amp
1490413-6 Nest Tyco/Amp
1490413-7 Nest Tyco/Amp
1490413-8 Nest Tyco/Amp
1490414-1 Indenter Tyco/Amp
1490414-2 Indenter Tyco/Amp
1490414-3 Indenter Tyco/Amp
ASSEMBLY OF INSULATED AND UNINSULATED TERMINAL LUGS
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-11
Page 117
Oct 15/2017D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
