• Layers of tape, refer to Paragraph 4.F.
• Heat shrinkable sleeves, refer to Paragraph 4.G..
Table 13
INSULATION REMOVAL LENGTH
Splice
Removal Length
(inch)
Target Tolerance
BACS52N-1 0.44 0.03
BACS52N-1A78 0.44 0.03
BACS52N-2 0.50 0.03
BACS52N-2A78 0.50 0.03
BACS52N-3 0.69 0.03
BACS52N-3A78 0.69 0.03
BACS52N-4 0.75 0.03
BACS52N-48 0.69 0.03
BACS52N-4A78 0.75 0.03
BACS52N-5 0.82 0.03
BACS52N-5A78 0.82 0.03
BACS52N-6 1.00 0.03
BACS52N-6A78 1.00 0.01
BACS52N-7 1.00 0.03
BACS52N-7A78 1.00 0.03
BACS52N-8 1.00 0.03
BACS52N-8A78 1.00 0.03
F. Increase of the O.D. of the Wire with Layers of Tape
This paragraph gives the procedure to increase the outer diameter of the wire insulation to make a seal
in the crimp barrel of the splice if the outer diameter is less than the minimum diameter specified in
Table 1 or Table 2.
(1) Make a selection of a solvent from Table 7.
(2) Make a selection of a TFE tape from Table 7.
(3) With a clean wiper and solvent, clean the wire insulation a minimum of 2.5 inches from the end of
the wire.
(4) Dry the clean area with clean wiper.
(5) Wind the necessary number of layers of tape on the wire insulation to make the O.D. of the wire
between the minimum and the maximum O.D. of the wire.
Make sure that the layers of tape make a 100 percent overlap.
ASSEMBLY AND REPAIR OF THE AMP AND BACS52N COPALUM SPLICES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-13
Page 15
Oct 15/2017D6-54446
ECCN 9E991 BOEING PROPRIETARY - See title page for details
