Table 45 CRIMP TOOLS FOR BACS52K() AND RAYCHEM D-609-() UNINSULATED BUTT SPLICES
(Continued)
Crimp Barrel Size
Crimp Tool
Basic Unit Supplier Nest
16-12
AD-1377 Tyco/Raychem 12-16
GMT232 Daniels 12-16
ST956C Boeing 12-16
ST956D Boeing 12-16
Table 46
CRIMP TOOLS FOR NICKEL PLATED UNINSULATED BUTT SPLICES
Crimp Barrel Size
Crimp Tool
Basic Unit Supplier Nest
22-18 46673 Tyco/AMP -
16-14
46988 Tyco/AMP -
59294 Tyco/AMP -
12-10 59461 Tyco/AMP -
B. Mechanical Ferrule Crimp Tools
Table 47
FERRULE CRIMP TOOLS
Outer Ferrule
Crimp Tool
Basic Unit
Die
Part Number Cavity
BACS13S101C
44-000 44-136 B
612648 612734 -
613214 613812 -
620175 620304 B
HX-4 Y136 B
M22520/5-01 M22520/5-33 B
ST2966M - -
ST965-19 - -
ST965A-19 - -
ST965B ST965B-19 -
WT219 - -
WT419 - -
WT440 4419 -
ASSEMBLY OF SPLICES
707, 727-787
STANDARD WIRING PRACTICES MANUAL
20-30-12
Page 39
Feb 15/2021D6-54446
