Table 15 CRIMP TOOLS FOR BACT13L TERMINAL LUGS (Continued)
Crimp Barrel Size
(Part Mark)
Terminal Lug
Crimp Tool
Power Unit Head Die Set
3/0AL - 2/0CU BACT13L-7 69120
1752787-1
59877-1
58422-1
3/0AL 13-78
BACT13L-7A78 69120
1752787-1
59877-1
58422-1
BACT13L-7A78-1 69120
1752787-1
59877-1
58422-1
BACT13L-7A78-2 69120
58422-1
59877-1
58422-1
4/0AL 13-78 BACT13L-8A78 69120
1752787-1
1976443-1
58422-1
(1) Make a selection of insulation sleeve. Refer to Paragraph 2.F..
(2) Remove the necessary length of wire insulation.
Refer to:
• Table 14
• Subject 20-00-15 for the procedures to remove the insulation.
(3) Make a selection of a power unit, crimp tool head, and die set from Table 11. Refer to Paragraph
2.H. for terminal assembly process.
E. Wire Preparation for BACT13T Copalum Terminals
Table 16
WIRE INSULATION REMOVAL LENGTH FOR BACT13T TERMINAL LUGS
Terminal Lug
Crimp Barrel Size
(Part Mark)
Removal Length
(inch)
Target Tolerance
BACT13T-5A60 1/0AL 13-60 0.82 ±0.03
BACT13T-5A78 1/0AL 13-78 0.82 ±0.03
BACT13T-6A78 2/0AL 13-78 1.00 ±0.03
BACT13T-7A78 3/0AL 13-78 1.00 ±0.03
BACT13T-8A78 4/0AL 13-78 1.00 ±0.03
