Table 15
CRIMP TOOLS FOR BACT13L TERMINAL LUGS
Crimp Barrel Size
(Part Mark)
Terminal Lug
Crimp Tool
Power Unit Head Die Set
6AL - 8CU BACT13L-2 69120
1752787-1
6800758422-1
69066
6AL 13-78
BACT13L-24A78 69120
1752787-1
680071752787-1
58422-1
BACT13L-2A78 69120
58422-1
6800769066
69066
4AL - 6CU BACT13L-3 69120
1752787-1
6800858422-1
69066
4AL 13-78
BACT13L-3A78
69120
1752787-1
68008BACT13L-3A78-1 58422-1
BACT13L-3A78-2 69066
2AL - 4CU BACT13L-4 69120
1752787-1
6800958422-1
69066
2AL 13-78
BACT13L-4A78
69120
1752787-1
68009BACT13L-4A78-1 58422-1
BACT13L-4A78-2 69066
1/0AL - 2CU BACT13L-5 69120
1752787-1
6801058422-1
69066
1/0AL 13-78 BACT13L-5A78 69120
1752787-1
68010-258422-1
69066
2/0AL - 1/0CU BACT13L-6 69120
1752787-1 68011-1
58422-1 68011-1
69066 314964-1
2/0AL 13-78
BACT13L-6A78
69120
1752787-1 68011-1
BACT13L-6A78-1 58422-1 68011-1
BACT13L-6A78-2 69066 314964-1
ASSEMBLY OF AMP (TYCO) COPALUM, MS25435 AND THOMAS & BETTS ALUMINUM
TERMINALS
707, 727-787
